Description
Thermostatic radiator valve designed for thermostatic and electrothermal controls, straight, with connection for 3/8" copper, plastic or multilayer pipe adapter
Radiator connection G 3/8" A (ISO 228-1) M inlet, straight connection
Pipe connection 23 p. 1.5 outlet, straight connection
Datasheet
• Straight connections, for simple and multilayer plastic copper pipe
• Pipe connections 23 p.1.5 and 3/4” M
• Radiator connection 3/8” and 1/2” M with tailpiece supplied with EPD sealing gasket
• Chromed brass body
• White RAL 9010 handwheel, for manual control, in ABS
• Stainless steel control rod
• Double seal on the control rod with EPDM O-Ring
• Temperature range 5÷100°C
• Maximum operating pressure 10 bar
