Description
Smart dimmer actuator designed to control dimmable lights via Wi-Fi, powered at 230 VAC, manages up to 150 W of load and can be controlled via the Smart Life app, voice commands (Alexa, Google Home) or via FEB Easy piezoelectric buttons, even in the absence of a Wi-Fi connection thanks to RF technology.
It is also compatible with traditional buttons connected directly to the module. The device supports long-press adjustment from the buttons; pressing more increases or decreases the brightness between 0 and 100%.
It also features a built-in button for Wi-Fi pairing, RF pairing, reset or manual control, an LED for operating status and an antenna for receiving wireless signals, durable and compact, it is ideal for smart home installations.
Datasheet
• Type Smart Wi-Fi dimmer for dimmable lights (LED / halogen)
• Power supply 230 VAC, 50–60 Hz
• Maximum power 150 W (dimmable LEDs)
• TRIAC dimming technology
• Wi-Fi wireless connections IEEE 802.11 b/g/n (2.4 GHz) and RF 433 MHz
• Smart Life app control, Alexa, Google Home, IFTTT
• Button compatibility up to 10 FEB Easy buttons
• Traditional button input supported
• Matching via integrated Wi-Fi/RF pairing button, reset, manual on/off
• Status LED indicates charging status and pairing mode
• RF range indoor ≤ 25 m, outdoor ≤ 60 m
• Dimming function via long button press
• Dimensions 44 × 44 × 22 mm
• Operating temperature –5 °C ÷ +50 °C
