Giacomini RM109Y043 - straight female threaded fitting 3/4 x (16 x 2)

Giacomini RM109Y043 - straight female threaded fitting 3/4 x (16 x 2)

SKU: GCMRM109Y043
Barcode: 8009902257552
Brand: Giacomini
straight female threaded fitting, press-fit multi-clamp 3/4" x (16 x 2)
€2.96pcs
⏰ Order now and receive it: between and
Based on the shipping address, VAT may change during the purchase process. For more information, click here.

Description

Straight female threaded fitting, multi-clamp press fitting and body in pressed brass from Ø 16 to 63 mm in cast brass from Ø 75 to 90 mm for plastic or multilayer pipes.

Double black O-Ring seal in EPDM for hydraulic systems and compression bushing in AISI 304 stainless steel.

Pressing profile TH, H, U for Ø 16, 20, 32 mm - TH, H for Ø 26 mm - TH, U for Ø 40, 50 mm - TH for Ø 63 mm - U for Ø 75, 90 mm.

Temperature range 5÷110 °C and maximum operating pressure 10 bar.

Datasheet

• Body in forged brass CW617N - EN 12165 (from Ø 16 to 63 mm); in cast brass CC770S - EN 1982 (from Ø 75 to 90 mm)

• Double black EPDM sealing O-ring compliant with EN 681-1 standard

• Maximum percentage of glycol diluted in water 50%

• Compression sleeve in stainless steel AISI 304

• Temperature range 5÷110 °C

• Maximum operating pressure 10 bar

Properties

Pressing profile:
H
U
TH
Cerifications:
C E
Thread:
F
Figure:
Straight fitting
Dimension:
DN 16
3/4"
Material:
Brass
Type of joint:
Threaded
To press
