Description
Robust modular electrical panel from the Orion Plus series, made of fibreglass-reinforced polyester resin, measuring 205 x 85 x 30 cm deep, is a double-compartment model and can be installed on the floor, even in protected outdoor environments.
It provides IP65 environmental protection, Class II insulation, and IK10 impact resistance and is RoHS compliant with REACH declarations available.
Inside, it has 12 modular rows (about 552 DIN modules) and supports a nominal current of up to 250 A.
Datasheet
• Dimensions 2050 × 850 × 300 mm
• Fiberglass reinforced polyester material
• IP65, IK10 protections
• Class II insulation
• Floor mounting (also external)
• Internal rows 12
• DIN module capacity approx. 552
• Rated current (In) 250 A
• RoHS environmental compliance, REACH declaration
