Description
The Hager HDA126L is a compact, fixed 4-pole circuit breaker, equipped with a TM type trip unit, designed for installation in electrical systems in the tertiary and industrial sectors, offering complete protection against overloads and short circuits.
Its rated current (In) is 125 A, while its ultimate breaking capacity (Icu) at 400 V AC is 18 kA.
Compliant with the IEC EN 60947-2 standard, it guarantees reliability and safety in interrupting the circuit in the event of a fault.
Datasheet
• Rated current (In) 125 A
• Breaking capacity (Icu) 18 kA at 400 V AC
• Number of poles 4
• Rated voltage (Ue) 440 V
• Insulation voltage (Ui) 690 V
• Impulse withstand voltage (Uimp) 8 kV
• Frequency 50/60 Hz
• Release type Thermomagnetic (TM)
• IP4X protection rating
• Dimensions (H x W x D) 130 x 100 x 68 mm
• Fixed installation, with front terminals
