AC/DC shunt trip coil, 24–48 V AC or 12–48 V DC control, 1 DIN module, for remote tripping of circuit breakers
Description
The Hager MZ204 is a compact single-module shunt trip coil intended for the remote activation of circuit breakers.
It supports both AC (24–48 V) and DC (12–48 V) control voltages, has an inrush power consumption of 27 VA, operates in an ambient temperature range of –25 °C to +60 °C and is characterised by nominal insulation up to 4000 V.
Datasheet
• Control voltage AC 24–48 V
• Power supply type AC/DC
• Inrush power consumption 27 VA
• Operating temperature –25 °C +60 °C
• Rated insulation voltage (Ui) 4000 V
• Dimensions 1 DIN module (83 x 18 x 68 mm)
Properties
Cerifications:
