Built-in shower
Stainless steel cover
Chrome finish
Timed 15 seconds, not adjustable
Suitable for connection to cold or premixed water
Description
The MODERN series built-in shower set is the ideal choice for any environment requiring controlled water use, such as gyms, swimming pools, and beach resorts. Its timed mechanism delivers water for approximately 15 seconds upon activation, automatically shutting off.
The flush-mounted installation makes the bathroom design minimalist and functional, as only the flush button and cover plate remain visible.
The product has been designed to withstand the wear and tear of time, ensuring reliability and minimizing the need for maintenance.
Datasheet
• Built-in body in chromed brass
• Push button operation
• Stainless steel cover rosette
• Chrome finish
• Flush-mounted installation
• Timed shutdown 15 seconds at 3 bar (tolerance: 15 ± 5 sec.) not adjustable
• Follow the flow arrow on the built-in body for correct installation
• Suitable for connection to cold or premixed water (if the supply is made with premixed water we recommend using a thermostatic mixer in the line)
• Supply temperature: 5 – 65 °C
• Recommended pressure: 2 – 4 bar
• Supply pressure: Min 1 – max 6 bar
• Clean surfaces with soap and water, avoiding aggressive detergents
Package contains:
• 1 Built-in brass body
• 1 External plate
• 1 Push button control
• Technical and installation manual
Any other installation accessories must be ordered separately
