Description
TCT101-4ABC-T is the most complete version, configurable for all the operating modes listed above (Timer / Counter / Tachometer) and equipped with ModbusRTU serial communication for the transmission of setpoints, Times / Counts / Frequency.
Equipped with a highly visible 6-digit LED display and an intuitive interface, it allows for quick setup and clear reading of real-time data.
The TCT101-4ABC-T supports multiple operation modes , including up and down counting, speed measurement and timed event management, making it ideal for applications in production lines, machinery and industrial plants.
Compatibility with PNP/NPN digital inputs and relay or solid-state outputs ensures easy integration into existing systems.
Datasheet
• Pixsys Model TCT101-4ABC-T
• Timer / counter / tachometer type
• 6-digit LED display
• PNP/NPN digital inputs
• Solid state relay outputs
• Up/Down counting mode
• Programmable time interval
• Power supply voltage 24V AC/DC
• Dimensions 32x74 mm
• Panel mounting
Package Contents:
• Timer / Counter / Tachometer Pixsys TCT101-4ABC-T
• User manual
• Mounting accessories
