Description
The Vimar Plana 14595.0 connected dimmer is a smart device compatible with both LE and TE lamps (loads from 20 to 200 W for LED lamps, incandescent lamps, or electronic transformers). It features dual wireless technology, Bluetooth 5.0 mesh and Zigbee 3.0, to work with View Wireless systems, Amazon Alexa, Google Assistant, or Apple HomeKit via a gateway.
The integrated soft-touch controls allow for ON/OFF and direct dimming, while the front RGB LED allows for easy recognition in the dark. Ideal for home automation scenarios, it can be activated by external controls (via the NO button) from up to 50 m away and configured via the app.
Datasheet
• Model 14595.0
• Type: IoT connected electronic dimmer
• Power supply 220‑240 V~ 50/60 Hz
• Load capacity LE/TE 20–200 W LED lamps, incandescent lamps, electronic transformers
• Bluetooth 5.0 mesh View Wireless & Zigbee 3.0 wireless technology
• Input for external NO button
• Soft-touch front controls (UP: ON/dimming up; DOWN: OFF/dimming down)
• Front RGB LED for device identification and configurations
• Assembly of 1 Plana module with minimum depth of 36.5 mm
Package Contents:
• 1 Vimar Plana 14595.0 dimmer mechanism
• Instruction manual
