Description
Centrifugal duct extractor, ideal for wall or ceiling installation in small residential and commercial environments, its structure is made of white ABS plastic resin, ensuring resistance and durability.
The device is equipped with a 2-speed induction motor with start capacitor, coupled to a forward-curved centrifugal impeller, and is also equipped with a thermal protection fuse and self-lubricating bushings, ensuring reliable and silent performance.
The flow rate varies from a minimum of 60 m³/h to a maximum of 85 m³/h, allowing for effective ventilation of the room, while the speed can be controlled using a Vortice regulator, offering flexibility in use.
Datasheet
• Nominal diameter 80 mm
• Maximum flow rate 85 m³/h
• Maximum power consumption 27 W
• Maximum speed 1,580 RPM
• Minimum speed 1,150 RPM
• Sound pressure level at 3 m at maximum speed 37 dB(A)
• Sound pressure level at 3 m at minimum speed 28.7 dB(A)
• IPX4 protection rating
• Insulation class II
• Material: White ABS plastic resin
• Wall or ceiling installation
• 2-speed motor
• Speed controllable by regulator
