3/8" straight thermostatic valve with copper or plastic/multilayer connection Ø 1/2" DN 16
Description
Valve with ABS handwheel, thermostatic, straight, nickel-plated, with connection for copper, plastic or multilayer pipe adapter.
Compatible with thermostatic actuators Series 148, 148A, 148SD and 148CD and electrothermal actuators Series 22C, 22CX, 22CX5 and 26LCa
Datasheet
• Valve body Brass CW617N
• ABS Flyer
• EPDM O-Ring
• CW617N Brass Nozzle
• Maximum permissible static pressure 10 bar
• Maximum differential pressure 1.5 bar
• Maximum temperature 110°C
• Usable liquids Water also with glycol ≤ 50%
Properties
Connector:
Plastic
Multilayer
Copper
Cerifications:
Form:
Straight
Dimension:
1/2"
Material:
Nickel-plated brass
