Description
Operation is automatic and occurs via a heat-sensitive element inserted in the valve body which, upon contact with the mixed water, expands and contracts, proportionally regulating the inlet of hot and cold water from the side outlets according to the set calibration value.
In the event of an accidental lack of cold water, the valve is equipped with a thermal cut-off device that promptly closes the shutter, preventing the entry of hot water to avoid the supply of unmixed water and therefore possible scalding.
Datasheet
• Maximum primary circuit temperature 100°C
• Maximum operating pressure 10 bar
• Maximum differential pressure 2 bar
• No. of calibration positions 4
• Anti-scald safety BSI 1415 standard
• Usable liquids Water
• Thermostatic element with solid expansion
• Stainless steel springs
• Brass Shutter
Properties
