Description
The 3-module recessed emergency lamp.
Based on the positioning of a jumper on the terminal block on the back, the lamp offers three different operations.
If there is a power failure, the LED lights up at maximum power.
If connected to a button, the lamp can be turned on or off like a common lamp / step light, and by connecting a button to the lamp, it is possible to turn the intensity of the LED on, off and dim. The set brightness level is stored until the next change.
The two signaling LEDs (red and green) communicate the activity status of the lamp: green with the battery charging and when the voltage fails, the safety lighting is activated, red indicates a malfunction.
It is possible to replace the rechargeable batteries by unhooking the front part from its seat. The battery pack is available as a spare part.
The 3 MODULES lamp is supplied as standard with 3 front panels in white, gray and anthracite to be compatible with the most popular domestic series.
It complies with the CEI 64-8 standard and the EN60598-2-22 standard which defines the characteristics of recessed products for emergency lighting.
Datasheet
Technical specifications:
• Power supply 230V 50/60 Hz
• IP20 protection rating
• Compatible with ABB Chiara, BTicino Living, Light, LivingLight and Matix, Gewiss Chorus, Vimar Arkè, Eikon and Plana series.
