Description
The DL175AX is designed for use in living environments with pets thanks to Animal Sense technology, it distinguishes between people and typical dog/cat movements avoiding false alarms.
It uses four PIR cells with double beam and dual radio frequency 868 + 433 MHz (TwinBand®), ensuring reliability and coverage up to 1,000 m in open field.
The detection range is 12 m with a 90° angle, and it is equipped with a test LED, self-protection against opening/tearing and anti-freeze function below 5 °C.
Powered by a RXU35X battery (3V–2.4Ah), it offers up to 6 years of battery life under normal operating conditions.
Datasheet
• Detection coverage 12m at 90°
• 4-cell PIR sensors with double beam
• Animal Sense technology (people/pets distinction)
• Two-way TwinBand radio (868 + 433 MHz), range 1 000 m
• LED power test and detection
• Anti-opening and anti-tearing self-protection
• Antifreeze technical alarm below 5 °C
• Power supply 1 × RXU35X (3 V‑2.4 Ah)
• Autonomy up to 6 years
• Degree of protection IP31, IK04
• Wall, corner, spherical support mounting
• Operating temperature –10 °C ÷ +55 °C
• Dimensions 58 × 102 × 57 mm
