Description
Smart actuator designed to control motorized roller shutters or curtains powered by mains voltage that offers four control modes: via the Smart Life app (2.4 GHz Wi-Fi), voice commands via Alexa or Google Home, FEB Easy piezo buttons and traditional buttons connected directly.
It features a built-in button for Wi-Fi/RF pairing, resetting settings or manually changing direction, two LEDs (red and green) indicate the active direction of the motor, while the extended RF antenna allows a range of up to 30m indoors and 100m outdoors.
Additionally, the actuators can act as RF repeaters to extend system coverage.
Compact (44 × 44 × 22 mm), it is ideal for flush-mounted installations in standard wall boxes, offering high home automation functionality in a small footprint.
Datasheet
• Smart Wi-Fi actuator for roller shutters (230 VAC)
• Smart Life App control compatibility, Alexa, Google Home, IFTTT
• IEEE 802.11 b/g/n (2.4 GHz) and RF 433 MHz Wi-Fi network connections
• Button connection up to 10 FEB Easy buttons; also compatible with traditional buttons
• Integrated Wi-Fi/RF pairing button, reset, motor direction reversal
• Red status LED for one motor direction, green for the other
• RF range indoor ≤ 30 m, outdoor ≤ 100 m
• Advanced RF repeater mode and full reset features
• Power supply 230 VAC
• Maximum supported motor power up to 390 W
• Dimensions 44 × 44 × 22 mm
• Operating temperature –5 °C ÷ +50 °C
