Description
Elegant recessed downlight designed for plasterboard (thickness 5–30 mm), with white painted aluminium body and spot optics.
Powered at 500 mA (external power supply required), it emits a warm light (3000 K) with high color rendering (CRI > 90) with a luminous flux of 735 lm.
Includes options for dimmable control and emergency kit.
Datasheet
• Indoor use application (IP20)
• Installation type: recessed in plasterboard (5–30 mm)
• Direct emission
• Spot optics
• Beam angle 36°
• Body color black
• Hole dimensions Ø65 mm, depth 60 mm, height H 105 mm
• Source power 10 W LED
• DC power supply 500 mA (power supply not included)
• Luminous flux of the luminaire 592 lm
• Source luminous flux 945 lm
• Color temperature 3000 K
• CRI > 90
• LED lifespan 50,000 h (L80 B20)
• Insulation class III
