Description
The 1 MODULE lamp performs the dual function of step marker lamp and auxiliary emergency lamp.
It complies with the Italian regulation CEI 64-8 which requires its installation in every home.
It is dimmable, in steplight mode it is possible to increase and decrease the power of the LED in order to allow the desired lighting effects.
In path light mode it is possible to set the twilight threshold at which you want the light to turn on automatically.
In the event of a power failure, the LED turns on at maximum power, guaranteeing the safety lighting necessary to move around the environment for approximately two hours.
The position of the LED and the finish of the transparent cover have been specifically designed to avoid glare. This makes it suitable for installation in civil and tertiary environments.
Datasheet
Technical specifications:
• Power supply 230V +/- 15% 50 Hz
• Light source 1 LED 0.5W 20 lumen
• Autonomy in case of black out approximately 2 hours
• Absorption 3 mA 0.7 VA
• IP20 protection rating
• Terminal cable section 0.75
• Dimensions 1 civil module in flush-mounting box
Certifications:
• THERE IS
